Szczegóły Produktu:
Zapłata:
|
| Tworzywo: | Odlewanie ciśnieniowe aluminium | Moc: | 160-240 W |
|---|---|---|---|
| Napięcie wejściowe: | 220-240VAC | Efekt optyczny: | 130 ~ 150 mb/w (opcjonalnie) |
| Stopień ochrony: | IP66 | Poziom ochrony: | IK08 |
| Współczynnik mocy: | PF≥0,95 | Indeks renderowania kolorów: | RA ≥70 |
| Zakres częstotliwości: | 50/60 Hz | Zakres warunków pracy: | -40 ~ 45 ℃ 20% ~ 90% wilgotności względnej |
| Rozmiar: | 650 x 320 x 75 mm | ||
| Podkreślić: | aluminium LED street light,high power road lighting,industrial LED street fixtures |
||
| Item No. | YASL-37-200 |
|---|---|
| Power | 40W |
| Lumen Efficiency | 130lm/w-150lm/w |
| Product Size (mm) | 445×250×75 |
| Working Voltage | AC100-265V | 50/60Hz |
|---|---|
| LED | LUMILEDS / OSRAM / CREE |
| CCT | 3000K, 4000K, 5000K, 5700K, 6500K |
| CRI | Ra>70 (standard)/ Ra>80 |
| Driver | PHILIPS/OSRAM/TRIDONIC/MEAN WELL/SOSEN/IEVENTRONICS |
| THD | <15% |
| Power Factor (PF) | PF>0.9 |
| IP Rating | IP66 |
|---|---|
| IK Rating | IK09 |
| Holder | 60mm |
| Body Material | High pressure die-cast aluminum |
| Housing Color | Dark Grey/Black/Light Grey (available on request) |
| Cover Material | UV-resistant Polycarbonate |
| Working Environment | -20℃ ~ +50℃, 10%~90%RH |
|---|---|
| Lifespan L70 at 25℃ | > 50,000hrs |
| Mounting Type | Side entry or Vertical pole mounted ±15° |
|---|---|
| Dimmable | 1-10V Dimming / Timer Dimming |
| Protection Class | Class I (standard) / Class II |
| Standards | CE, RoHS, ENEC, CB, LM79, LM80, TM-21, IP66, IK09 |
|---|---|
| Available on request | NEMA socket (3/5/7pins), ZHAGA socket, Short cap, Photocell, Motion sensor, NTC, OLC, DALI Dimming |
